Product: All-in-one machine (Cylinder hydraulic test, volume measurement, water pouring, loading and unloading valve machine)
Main structure and characteristics
The main configuration of this valve loading and unloading device machine: 1. valve loading and unloading device, and water pouring device constitute the main part of the pressure test device; 2. electric pressure test pump and measuring cylinder. If no need the pressure test part, this device becomes a valve loading and unloading and water pouring machine.
Main technical parameters
a. Rated hydraulic test pressure P1=22.5mpa
b. The spindle installed valve automatically controls the torque M1=300NM
c. The maximum torque of the spindle unloading valve M2=450NM
d. Pouring angle R=160°
e. Drive motor model Y90S—4—1.1KW
Power 1.1KW
Speed 1400r/min
f. Power supply 380V/50HZ
g. Air source P=0.75mpa (safe gas)
h. Spindle up and down stroke S1=500mm
i. Clamping mechanism stroke S2=100mm
j. Dimensions 1500*800*2700
k. Valve cylinder specifications to be loaded and unloaded, diameter 210-220
l. Spindle speed: 15r/min
